Formlabs ESD Resin (Form 3) - 1L is a specialized electrostatic dissipative material engineered to reduce the risk of static discharge in sensitive electronics manufacturing environments. This resin is specifically developed for the Form 3 ecosystem, providing a robust solution for creating custom tools, jigs, and fixtures that protect sensitive components from electrostatic damage. Consequently, it is the essential choice for Australian electronics manufacturers and industrial engineers looking to integrate high-resolution 3D printing into their static-safe production lines whilst maintaining strict ESD compliance.
Industrial Static Control with Formlabs ESD Resin (Form 3) - 1L
The Formlabs ESD Resin (Form 3) - 1L offers high modulus and high strength, ensuring that ESD-safe fixtures do not compromise on durability. Unlike secondary coatings or ESD-safe tapes, the dissipative properties of this resin are inherent to the material throughout the entire part. Furthermore, the material's matte black finish provides a professional aesthetic whilst its resistance to common industrial solvents allows for repeated use in rigorous assembly environments across Australia.
Mechanical Properties and ESD Specifications
Whilst prioritising electrical conductivity, this resin maintains the precision required for complex mechanical assemblies. The following properties are validated for parts post-cured at 60°C for 60 minutes:
| Technical Property | Value (Post-Cured) |
|---|---|
| Surface Resistivity | 10^5 – 10^8 Ω/sq |
| Ultimate Tensile Strength | 36 MPa |
| Tensile Modulus | 2.3 GPa |
| Flexural Modulus | 2.0 GPa |
| Heat Deflection Temp @ 0.45 MPa | 90°C |
Workflow Integration for Static-Safe Zones
Utilising Formlabs ESD Resin (Form 3) - 1L in an Australian manufacturing facility requires a specific post-processing protocol to ensure electrical properties are uniform. Parts must be washed in Isopropyl Alcohol (IPA) for 20 minutes and post-cured at 60°C for 60 minutes. Because the material contains carbon-based additives, regular tank maintenance is advised to prevent sedimentation. This resin enables the rapid replacement of metal or machined ESD-safe components, significantly reducing lead times for production floor customisation.
